6WH28C2500-7.51838KW750RPM
6WH28C2790-6.5 2050KW 650RPM
6WH28C2856-6.5 2100KW 650RPM
6WH28C2938-7.2 2160KW 720RPM
6WH28C3000-7.5 2206KW 750RPM
6WH28C3046-7.2 2240KW 720RPM
6WH28C3046-7.5 2240KW 750RPM
6WH28C3264-7.5 2400KW 750RPM
6WH28C3264-8 2400KW 800RPM
6WH28C3400-8 2499KW 800RPM
6WH28C3500-8 2574KW 800RPM
6WH28C3672-8 2700KW 800RPM
8WH28C3808-6.5 2800KW 650RPM
8WH28C4000-7.2 2942KW 720RPM
8WH28C4080-7.5 3000KW 750RPM
8WH28C4352-7.5 3200KW 750RPM
8WH28C4515-8 3320KW 800RPM
8WH28C4896-8 3600KW 800RPM
| Engine | Model | Rated power（kW/Ps） | Speed（r/min） |
| 6WH28 | 6WH28C2500-7.5 | 1838/2500 | 750 |
| 6WH28C2790-6.5 | 2050/2790 | 650 | |
| 6WH28C2856-6.5 | 2100/2856 | 650 | |
| 6WH28C2938-7.2 | 2160/2938 | 720 | |
| 6WH28C3000-7.5 | 2206/3000 | 750 | |
| 6WH28C3046-7.2 | 2240/3046 | 720 | |
| 6WH28C3046-7.5 | 2240/3046 | 750 | |
| 6WH28C3264-7.5 | 2400/3264 | 750 | |
| 6WH28C3264-8 | 2400/3264 | 800 | |
| 6WH28C3400-8 | 2499/3400 | 800 | |
| 6WH28C3500-8 | 2574/3500 | 800 | |
| 6WH28C3672-8 | 2700/3672 | 800 | |
| 8WH28 | 8WH28C3808-6.5 | 2800/3808 | 650 |
| 8WH28C4000-7.2 | 2942/4000 | 720 | |
| 8WH28C4080-7.5 | 3000/4080 | 750 | |
| 8WH28C4352-7.5 | 3200/4352 | 750 | |
| 8WH28C4515-8 | 3320/4515 | 800 | |
| 8WH28C4896-8 | 3600/4896 | 800 |
| WH28 Engine Parameter | ||
| 型式 Type | 直列、四冲程、直喷、涡轮增压、不可逆转 In-line,Four strokes, Turbocharger, Non-reversible | |
| 气缸数 No. of cylinders | 6 and 8 | |
| 气缸直径 Cylinder bore | mm | 280 |
| 活塞行程 Piston stroke | mm | 410 |
| 总排量 Total displacement | L | 151.5L/202L |
| 机油消耗率 Lubricating oil consumption | g/kW·h | ≤0.5g/kW·h |
| 噪声 Noise | dB(A) | ≤114dB（A） |
| 起动方式 Starting method | 气起动和电起动 Air motor or electric motor | |
| 最低工作稳定转速(RPM) Minimum stable speed | r/min | 320 |
| 整机质量 Net weight | kg | 6 Cylinders:24000 8 Cylinders: 29000 |
| 曲轴旋转方向（面向飞轮端） Direction of crankshaft rotation (facing the flywheel end) | 逆时针 Anticlockwise | |
| 外形尺寸(长×宽×高) Overall dimension | mm | 6 Cylinders: 5068×1967×3510 8 Cylinders: 5972×1967×3520 |
