12M55C1850-16E210 1361KW 1600RPM
12M55C2030-16E210 1493KW 1600RPM
12M55C2250-16E210 1654KW 1600RPM
12M55C2450-16E210 1801KW 1600RPM
12M55C2535-16E210 1864KW 1600RPM
12M55C2250-18E211 1654KW 1800RPM
12M55C2450-18E211 1801KW 1800RPM
12M55C2600-18E211 1912KW 1800RPM
12M55C2738-18E211 2013KW 1800RPM
12M55C3000-18E211 2205KW 1800RPM
12M55C3200-18E211 2352KW 1800RPM
12M55C3450-18E211 2536KW 1800RPM
| Engine | Model | Rated power（kW/Ps） | Speed（r/min） |
| 12M55* | 12M55C1850-16E210 | 1361/1850 | 1600 |
| 12M55C2030-16E210 | 1493/2030 | 1600 | |
| 12M55C2250-16E210 | 1654/2250 | 1600 | |
| 12M55C2450-16E210 | 1801/2450 | 1600 | |
| 12M55C2535-16E210 | 1864/2535 | 1600 | |
| 12M55C2250-18E211 | 1654/2250 | 1800 | |
| 12M55C2450-18E211 | 1801/2450 | 1800 | |
| 12M55C2600-18E211 | 1912/2600 | 1800 | |
| 12M55C2738-18E211 | 2013/2738 | 1800 | |
| 12M55C3000-18E211 | 2205/3000 | 1800 | |
| 12M55C3200-18E211 | 2352/3200 | 1800 | |
| 12M55C3450-18E211 | 2536/3450 | 1800 |
| 12M55 Engine Parameter | ||
| 型式 Type | V型、四冲程、直喷、涡轮增压、不可逆转 V-Type, Four strokes, Turbocharger, Non-reversible | |
| 气缸数 No. of cylinders | 12 | |
| 气缸直径 Cylinder bore | mm | 180 |
| 活塞行程 Piston stroke | mm | 215 |
| 总排量 Total displacement | L | 65.65L |
| 机油消耗率 Lubricating oil consumption | g/kW·h | ≤0.8g/kW·h |
| 噪声 Noise | dB(A) | ≤105dB（A） |
| 起动方式 Starting method | 电起动 Electric motor | |
| 最低工作稳定转速(RPM) Minimum stable speed | r/min | 650 |
| 整机质量 Net weight | kg | 95000 |
| 曲轴旋转方向（面向飞轮端） Direction of crankshaft rotation (facing the flywheel end) | 逆时针 Anticlockwise | |
| 外形尺寸(长×宽×高) Overall dimension | mm | 2927×1565×2637 |
