16V170ZLC-1 956KW 1000RPM
16V170ZLC-2 1103KW 1200RPM
16V170ZLC-3 1470KW 1500RPM
16V170ZLC-4 1618KW 1800RPM
16V170ZLC-5 1470KW 1800RPM
12V170ZLC-1 637KW 1000RPM
12V170ZLC-2 735KW 1200RPM
12V170ZLC-3 1103KW 1500RPM
12V170ZLC-4 1213KW 1800RPM
12V170ZLC-5 1103KW 1800RPM
| 型号 Model | 16V170ZLC-1 | 16V170ZLC-2 | 16V170ZLC-3 | 16V170ZLC-4 | 16V170ZLC-5 |
| 型式 Type | V型机60°、四冲程、直喷、涡轮增压、不可逆转 V type 60°, Four strokes, Turbocharger, Non-reversible | ||||
| 持续功率(kW/PS) Rated power | 956/1300 | 1103/1500 | 1470/2000 | 1618/2200 | 1470/2000 |
| 持续转速(rpm) Rated speed | 1000 | 1200 | 1500 | 1800 | 1800 |
| 气缸直径(mm) Cylinder bore | 170 | ||||
| 活塞行程(mm) Piston stroke | 200 | ||||
| 气缸数 No. of cylinders | 16 | ||||
| 总排量(L) Total displacement | 72.63 | ||||
| 压缩比 Compression ratio | 14.5 | ||||
| 最低工作稳定转速(RPM) Minimum stable speed | 400 | 480 | 600 | 720 | 720 |
| 活塞平均速度(m/s) Mean piston speed | 6.67 | 8 | 10 | 12 | 12 |
| 平均有效压力(Mpa) Mean effective pressure | 1.58 | 1.52 | 1.62 | 1.48 | 1.35 |
| 增压压力(绝对)(Mpa) Turbocharged pressure (Absolute) | 0.24±0.01 | 0.24±0.01 | 0.26±0.01 | 0.26±0.01 | 0.25±0.01 |
| 最高爆发压力(Mpa) Maximum explosive pressure | ≤14 | ||||
| 各缸排气温度(℃) Each cylinder exhaust temperature | ≤550 | ||||
| 涡轮前排温(℃) Exhaust temperature before turbocharger | ≤600 | ||||
| 燃油消耗率(g/kw.h) Fuel oil consumption | 198 | ||||
| 机油消耗率(g/kw.h) Lubricating oil consumption | 1.0 | ||||
| 旋转方向 Rotation | 右转为顺时针，左转为逆时针 Turn right clockwise, turn left counterclockwise | ||||
| 起动方式 Starting method | 气起动或电起动 Air motor or electric motor | ||||
| 冷却方式 Cooling method | 闭式冷却Closed water cooling | ||||
| 润滑方式 Lubricating method | 压力润滑Pressure lubricting | ||||
| 外形尺寸(长×宽×高) Overall dimension | 3554×1470×1840 | ||||
| 吊缸高度 Piston hang height | 1027 | ||||
| 整机质量（kg） Net weight | 8800 | ||||
| 型号 Model | 12V170ZLC-1 | 12V170ZLC-2 | 12V170ZLC-3 | 12V170ZLC-4 | 12V170ZLC-5 |
| 型式 Type | V型机60°、四冲程、直喷、涡轮增压、不可逆转 V type 60°, Four strokes, Turbocharger, Non-reversible | ||||
| 持续功率(kW/PS) Rated power | 637/866 | 735/1000 | 1103/1500 | 1213/1650 | 1103/1500 |
| 持续转速(rpm) Rated speed | 1000 | 1200 | 1500 | 1800 | 1800 |
| 气缸直径(mm) Cylinder bore | 170 | ||||
| 活塞行程(mm) Piston stroke | 200 | ||||
| 气缸数 No. of cylinders | 12 | ||||
| 总排量(L) Total displacement | 54.48 | ||||
| 压缩比 Compression ratio | 14.5 | ||||
| 最低工作稳定转速(RPM) Minimum stable speed | 400 | 480 | 600 | 720 | 720 |
| 活塞平均速度(m/s) Mean piston speed | 6.67 | 8 | 10 | 12 | 12 |
| 平均有效压力(Mpa) Mean effective pressure | 1.58 | 1.52 | 1.62 | 1.48 | 1.35 |
| 增压压力(绝对)(Mpa) Turbocharged pressure (Absolute) | 0.24±0.01 | 0.24±0.01 | 0.26±0.01 | 0.26±0.01 | 0.25±0.01 |
| 最高爆发压力(Mpa) Maximum explosive pressure | ≤14 | ||||
| 各缸排气温度(℃) Each cylinder exhaust temperature | ≤550 | ||||
| 涡轮前排温(℃) Exhaust temperature before turbocharger | ≤600 | ||||
| 燃油消耗率(g/kw.h) Fuel oil consumption | 198 | ||||
| 机油消耗率(g/kw.h) Lubricating oil consumption | 1.0 | ||||
| 旋转方向 Rotation | 右转为顺时针，左转为逆时针 Turn right clockwise, turn left counterclockwise | ||||
| 起动方式 Starting method | 气起动或电起动 Air motor or electric motor | ||||
| 冷却方式 Cooling method | 闭式冷却Closed water cooling | ||||
| 润滑方式 Lubricating method | 压力润滑Pressure lubricting | ||||
| 外形尺寸(长×宽×高) Overall dimension | 2912×1374×1840 | ||||
| 吊缸高度 Piston hang height | 1027 | ||||
| 整机质量（kg） Net weight | 7300 | ||||
