Oil tanker 11000DWT

Ship type	Oil Tanker, Double Hull	下次特检日期	2026/5/31
Gross tonnage	7,963	净吨位
Load capacity ton	10,978	Length overall	138.16
Length between vertical lines	130.5	Mould width	19
Mould Depth	10.7	Freeboard	3512
Average draft depth	7.2	Ship's speed	12.3
Ship classification symbol	★CSA	Additional hull markings	F.P. ≤ 60℃;Ice Class B;R1(D)
Marine engine classification symbol	★CSM	Marine engine additional markings
Superstructure and Deck Room	Deckhouse:17.10,Forecastle:13.57,Poop:23.56	Number of Deck Layers	1,Upper Deck
Number of bulkheads	10,Fr.Nos.6,31,38,57,81,105,129,153,174,180	Ballast	5140
Shipyard	ZHEJIANG	Ship construction location	China
Ship construction time	2021/6/1	重大改建部位的建造日期
重大改建情况		Main engine factory	GUANGZHOU DIESEL ENGINE FACTORY CO.,LTD
锅炉建造厂	Jiangyin Sanjie Industry Co.,Ltd.	Main engine manufacturing time	2020/11/15
锅炉建造时间		Main engine type * quantity	6G32A*1;
Number of main engine cylinders * cylinder diameter * power * speed	63202930.00*600	Generator * Power * Voltage * quantity	SB-HW4-300-6P300.004002; SB-HW4.D-150150.004001;
锅炉数压力受热面积 Number of boilers * Pressure * Heating surface area	10.5/45.00 m2	集装箱数*规格	dk:;ho:
Number of cargo holds	12	货舱总容积 Total cargo hold capacity	14545.34 M3
舱口数及舱口尺度 Number of hatches and hatch dimensions	12*Dia.1.0	起货设备类型,安全负荷,数量
各货舱容积 Capacity of each cargo hold	NO.1C.O.T.(P)(G944.07) ;NO.1C.O.T.(S)(G963.86) ;NO.2C.O.T.(P)(G1332.15) ;NO.2C.O.T.(S)(G1308.41) ;NO.3C.O.T.(P)(G1314.27) ;NO.3C.O.T.(S)(G1338.01) ;NO.4C.O.T.(P)(G1338.01) ;NO.4C.O.T.(S)(G1314.27) ;NO.5C.O.T.(P)(G1314.26) ;NO.5C.O.T.(S)(G1338.00) ;NO.6C.O.T.(P)(G1029.41) ;NO.6C.O.T.(S)(G1010.62)
