| Ship type | Oil Tanker, Double Hull | 下次特检日期 | 2026/8/19 |
| Gross tonnage | 5,757 | 净吨位 | |
| Load capacity ton | 7,487 | Length overall | 119.98 |
| Length between vertical lines | 112.4 | Mould width | 17.4 |
| Mould Depth | 9.3 | Freeboard | 2812 |
| Average draft depth | 6.5 | Ship's speed | 12 |
| Ship classification symbol | ★CSA | Additional hull markings | F.P. ≤ 60℃;Ice Class B;R1(D) |
| Marine engine classification symbol | ★CSM | Marine engine additional markings | |
| Superstructure and Deck Room | Deckhouse:17.20,Forecastle:12.23,Poop:23.55 | Number of Deck Layers | 1,Upper Deck |
| Number of bulkheads | 8,Fr.Nos.4,30,35,67,95,123,149,155 | Ballast | 3346 |
| Shipyard | Linhai Huajie Shipbuilding Co., Ltd. | Ship construction location | China |
| Ship construction time | 2021/8/20 | 重大改建部位的建造日期 | |
| 重大改建情况 | Main engine factory | NINGBO C.S.I. POWER & MACHINERY GROUP CO., LTD. | |
| 锅炉建造厂 | Jiangyin Sanjie Industry Co.,Ltd. | Main engine manufacturing time | 2021/1/14 |
| 锅炉建造时间 | Main engine type * quantity | GN8320ZC4B*1; | |
| Number of main engine cylinders * cylinder diameter * power * speed | 8*320*2795.00*630 | Generator * Power * Voltage * quantity | TFXW-315M4-H*200.00*400*3; |
| 锅炉数*压力*受热面积 Number of boilers * Pressure * Heating surface area | 1*0.5*/45.00 m2 | 集装箱数*规格 | dk:;ho: |
| Number of cargo holds | 8 | 货舱总容积 Total cargo hold capacity | 10237.10 M3 |
| 舱口数及舱口尺度 Number of hatches and hatch dimensions | 8*Dia.1.0 | 起货设备类型,安全负荷,数量 | |
| 各货舱容积 Capacity of each cargo hold | NO.1C.O.T.(P)*(G1003.34) ;NO.1C.O.T.(S)*(G977.88) ;NO.2C.O.T.(P)*(G1373.33) ;NO.2C.O.T.(S)*(G1401.84) ;NO.3C.O.T.(P)*(G1409.21) ;NO.3C.O.T.(S)*(G1380.70) ;NO.4C.O.T.(P)*(G1331.40) ;NO.4C.O.T.(S)*(G1359.40) | ||
