Refrigerated Cargo Ship 3600 DWT

Refrigerated Cargo Ship 3600DWT

Ship type	Refrigerated Cargo Ship	下次特检日期	2025/1/2
Gross tonnage	3,601	净吨位	1,539
Load capacity ton	3,652	Length overall,m	102.6
Length between vertical lines,m	93.2	Mould width,m	15.8
Mould Depth，m	9	Freeboard	3112
Average draft depth,m	5.9	Ship's speed	13.5
Ship classification symbol	★CSA	Additional hull markings	CRS(No.1、2、3、4 Hold -25℃, 35℃ Max.Sea Water)
Marine engine classification symbol	★CSM	Marine engine additional markings
Superstructure and Deck Room	Deckhouse:16.75,Forecastle:9.29	Number of Deck Layers	2 & Upper deck,2nd deck
Number of bulkheads	7;Fr.Nos 9,31,57,83,108,134,140	Ballast
Shipyard	Zhejiang Xinzhou Shipbuilding Co., Ltd.	Ship construction location	China
Ship construction time	2020/1/3	重大改建部位的建造日期
重大改建情况		Main engine factory	Qingdao Zichai Boyang Diesel Engine Co.,Ltd.
锅炉建造厂	Wuxi Hitop Boiler Co.,Ltd.	Main engine manufacturing time	2019/9/15
锅炉建造时间		Main engine type * quantity	ZC6330ZLC-13*1;
Number of main engine cylinders * cylinder diameter * power * speed	63302574.00*580	Generator * Power * Voltage * quantity	SB-HW4-400-6P400.004002; SB-HW4.D-9090.004001;
锅炉数压力受热面积 Number of boilers * Pressure * Heating surface area	10.70013.00/90.00 m2	集装箱数*规格	dk:;ho:
Number of cargo holds	8	货舱总容积 Total cargo hold capacity	5925.43 M3
舱口数及舱口尺度 Number of hatches and hatch dimensions	44.61×5.45; 43.9×3.9	起货设备类型,安全负荷,数量
各货舱容积 Capacity of each cargo hold	No.1 FISH HOLD (D)(B428.17) ;No.1 FISH HOLD (U)(B679.91) ;No.2 FISH HOLD (D)(B761.79) ;No.2 FISH HOLD (U)(B850.95) ;No.3 FISH HOLD (D)(B855.26) ;No.3 FISH HOLD (U)(B889.42) ;No.4 FISH HOLD (D)(B570.07) ;No.4 FISH HOLD (U)(B889.86)
