Oil tanker 12190 DWT

Ship type	Oil Tanker, Double Hull	下次特检日期	2029/12/23
Gross tonnage	9,311	净吨位
Load capacity ton	13271.2	Length overall,m	139.8
Length between vertical lines,m	131.9	Mould width,m	20
Mould Depth，m	11.2	Freeboard	3212
Average draft depth,m	8	Ship's speed	13
Ship classification symbol	★CSA	Additional hull markings	F.P. ≤ 60℃;Ice Class B;R1(D)
Marine engine classification symbol	★CSM	Marine engine additional markings	BRC;Gd-EP(VCS)
Superstructure and Deck Room	Deckhouse:20.50,Forecastle:13.82,Poop:26.36	Number of Deck Layers	1,Upper Deck
Number of bulkheads	9,Fr.Nos.5,35,60,83,106,129,153,176,182	Ballast	6048
Shipyard	Zhejiang	Ship construction location	China
Ship construction time	2024/12/24	重大改建部位的建造日期
重大改建情况		Main engine factory	Guangzhou Diesel Engine Factory Co.,Ltd. Jingjiang Co.,Ltd.
锅炉建造厂	Jiangyin Sanjie Boiler Co.,Ltd.	Main engine manufacturing time	2024/3/15
锅炉建造时间		Main engine type * quantity	GDF-J-ENG 6UEC33LSE-C2(SCR)*1;
Number of main engine cylinders * cylinder diameter * power * speed	63002880*121.0	Generator * Power * Voltage * quantity	SB-HW4.D-300250.004002; SB-HW4.D-500250.004002;
锅炉数压力受热面积 Number of boilers * Pressure * Heating surface area	10.7/65 m2	集装箱数*规格	dk:;ho:
Number of cargo holds	12	货舱总容积 Total cargo hold capacity	16374.56 M3
舱口数及舱口尺度 Number of hatches and hatch dimensions	12*Dia.1.0	起货设备类型,安全负荷,数量
各货舱容积 Capacity of each cargo hold	NO.1C.O.T.(P)(G1085.50) ;NO.1C.O.T.(S)(G1117.77) ;NO.2C.O.T.(P)(G1484.77) ;NO.2C.O.T.(S)(G1449.56) ;NO.3C.O.T.(P)(G1399.84) ;NO.3C.O.T.(S)(G1433.58) ;NO.4C.O.T.(P)(G1433.58) ;NO.4C.O.T.(S)(G1399.84) ;NO.5C.O.T.(P)(G1393.79) ;NO.5C.O.T.(S)(G1427.53) ;No.6C.O.T.(P)(G1390.54) ;No.6C.O.T.(S)(G1358.26)
